TANKS
FUEL LUBE MODULES & WATER TANKS
THE GECKO TANK IS BY FAR THE MOST INNOVATIVE TANK DESIGN ON THE MARKET
- Proven in world class mining operations
- Frontline asset for reducing your cost of fleet maintenance
- Manufactured to ensure safer work practices
- Flexibility to meet your site requirements and specifications
- International Patent Approved
OFFERING FLEXIBILITY AND UNCOMPROMISING QUALITY AT A COMPETITIVE PRICE
INTEGRATED STEEL AND ALUMINIUM CONSTRUCTION
Additional Options Available for Shipment
GECKO 100 TON AND 60 TON FUEL LUBE MODULE
CATERPILLAR 777F WITH 72000LT (19000GL)
SIDE DISPENSING AND FAST FILL
CABINETS ELIMINATE NEED OR WORK
BEHIND THE VEHICLE EXCEPT DURING
SCHEDULED MAINTENANCE OR REPAIRS
CATERPILLAR 775F WITH 42000LT (11000GL)
LIGHT WEIGHT DURABLE ALUMINIUM
COMPARTMENT ACCESS PANELS
- Easily accessible component lay out
- Centralised control and test station
- Multiple access points for maintenance
- Filters, screens and breathers grouped for easy access
- High pressure washer included
- Redundant emergency shutoff mechanisms
- Environmentally sound self bundled distribution cabinet
- Hydraulic retractable reels With pre-set rolling torques (rigid frame units)
Dual Dispensing up to 980 LPM (250GPM)
ROBUST TANK CONSTRUCTION
GECKO 40-45 TON FUEL LUBE MODULE WITH 29000LT (7600GL)
BUILD SPECIFICATION
- All steel is a minimum ASTM36
- Single piece construction of top sides and bottom plates
- Dynamic loading, proven stability and anti-sloshing
- Low center of gravity and even weight distribution
- Epinamel TL710 marine grade corrosion resistant intenor enamel coating ensures tank integrity
- Fast fill on all product tanks
- Interactive training, service, operation and parts manuals
- Tested, calibrated and pre-commissioned pre-delivery
- Oil and fuel compartments can be custom designed to suit customers requirements
- Convertible to/from service truck or water truck post manufacture
SAFETY SPECIFICATION
- ADG Code 7.3: Australian Dangerous Goods Code Edition 7.3
- AS/NZS 1554: Structural Steel Welding Set (2011)
- AS 2809.1: Road tank vehicle for dangerous goods — General requirements for all road tank vehicles (2008)
- AS 2809.2: Road tank vehicle for dangerous goods - Road tank vehicles for flammable liquids (2008)
- AS 4100: Steel Structures
- AS 3990: Mechanical Equipment Steel Work
EXTREME COLD WEATHER PACKAGE OPTIONS
3X30,000 BTU HEATING UNITS FOR HEATING HOSE REEL AND PUMPING COMPARTMENT
2 X WABASTO DBW 350 THERMO HEATERS FOR HEATING PRODUCT COMPARTMENT
GLYCOL HEATING COILS FOR PRODUCT TANKS
OPTIONAL TRANSPORT STAND FOR SAFE AND EASY SHIPPING
CAPACITIES
| Cat Equivalents | 740 | 775 | Haulmax | 777 | 785 |
|
|---|---|---|---|---|---|---|
| Compartment | Product | 40-45 Ton 29000LT (7600GL) | 60 Ton 42000 LT (11000GL) | 70 Ton 63000 LT (16600GL) | 100 Ton 72000 LT (19000GL) | 150 Ton 120000 LT (31700GL) |
| 1 | Oil 1 | 985Lt (260gl) | 1200Lt (320gl) | 1400Lt (370gl) | 1300Lt (345gl) | 2290Lt (605gl) |
| 2 | Oil 1 | 985Lt (260gl) | 1200Lt (320gl) | 1400Lt (370gl) | 1300Lt (345gl) | 2290Lt (605gl) |
| 3 | Oil 1 | 985Lt (260gl) | 1100Lt (290gl) | 1400Lt (370gl) | 1200Lt (320gl) | 1970Lt (520gl) |
| 4 | Oil 1 | 985Lt (260gl) | 1100Lt (290gl) | 1400Lt (370gl) | 1200Lt (320gl) | 1970Lt (520gl) |
| 5 | Oil 1 | 985Lt (260gl) | 950Lt (250gl) | 1400Lt (370gl) | 1100Lt (290gl) | 1650Lt (435gl) |
| 6 | Oil 1 | 985Lt (260gl) | 950Lt (250gl) | 1400Lt (370gl) | 1100Lt (290gl) | 1650Lt (435gl) |
| 7 | Coolant 7 | 635Lt (165gl) | 850Lt (225gl) | 1300Lt (345gl) | 950Lt (250gl) | 1520Lt (400gl) |
| 8 | Water 8 | 635Lt (165gl) | 850Lt (225gl) | 1300Lt (345gl) | 950Lt (250gl) | 1520Lt (400gl) |
| 9 | Oil 9 | N/A | N/A | 1200Lt (320gl) | 1250Lt (330gl) | 2290Lt (605gl) |
| 10 | Oil 10 | N/A | N/A | 1200Lt (320gl) | 1200Lt (320gl) | 1970Lt (520gl) |
| 11 | Oil 11 | N/A | N/A | N/A | 1150Lt (300gl) | 1650Lt (435gl) |
| 12 | Oil 12 | N/A | N/A | N/A | N/A | 1520Lt (400gl) |
| 13 | Grease | 400Kg (880lb) | 500Kg (1100lb) | 500Kg (1100lb) | 600Kg (1320lb) | 600Kg (1320lb) |
| 14 | Fuel | 21589lt (5700gl) | 34000lt (8980gl) | 50000lt (13200gl) | 62000lt (16380gl) | 97700lt (25810gl) |
| 15 | Air | 60cfm | 60cfm | 60cfm | 60cfm | 60cfm |
